6015 MAX 12000W Fiber Laser Metal Engraving Machine Cnc Laser Cutting Machine

Name: 6015 MAX 12000W Fiber Laser Metal Engraving Machine Cnc Laser Cutting Machine
Brand: Honest
Price: 16800 USD

Quality 6015 MAX 12000W Fiber Laser Metal Engraving Machine Cnc Laser Cutting Machine wholesale

Brand Name : Honest

Model Number : 6015

Certification : CE ISO

Place of Origin : China

MOQ : 1

Price : 16800$-30000$ per one set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,Trade Assurance

Supply Ability : 10 per a month

Delivery Time : 10-20 wooking days

Packaging Details : wooden package

Cutting thickness : Materials

Graphic format supported : DXF,PLT,AI,DST,BMP

Control software : Cypcut

Cooling mode : Water Cooling

Warranty : 2 Years

Cutting area : 6000*1500mm

After-sales service provided : Engineers available to service machinery overseas

Laser source : Raycus or IPG or Max

Contact Now

6015 MAX 12000W Fiber Laser Metal Engraving Machine Cnc Laser Cutting Machine

Product Advantages

The advantages of fiber laser cutting machine:

Excellent path quality: Smaller laser dot and high work efficiency, high quality.
High cutting speed: cutting speed is 2-3 times than same power CO2 laser cutting machine.
Stable running: adopt top world import fiber lasers, stable performance, key parts can reach 100,000 hours;
High efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, fiber laser cutting machine have three
 times photoelectric conversion efficiency.
Low cost: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption,
 it is only about 20%-30% of traditional CO2 laser cutting machine.
Low maintenance: fiber line transmission no need reflect lens, save maintenance cost;
Easy operations: fiber line transmission, no adjustment of optical path.

product details

Feature/Model	HN3015	HN4015	HN4020
Working Area (L*W))	3000mm*1500mm	4000mm*1500mm	4000mm*2000mm
Stroke (X/ Y/ Z Axis)	1525mm/3025mm/150mm	1525mm/4025mm/150mm	2025mm/4025mm/150mm
X/Y Axis Positioning Accuracy	±0.03mm/m	±0.03mm/m	±0.03mm/m
X/Y Axis Repositioning Accuracy	±0.03mm	±0.03mm	±0.03mm
Max. Moving Speed	110m/min	110m/min	110m/min
Max. Acc. Speed	1.0G	1.0G	1.0G
Power Porection Grade	IP54	IP54	IP54
Laser Power	1500W~4000W	1500W~4000W	1500W~4000W
Max. Loading Weight	800kg	1000kg	1400kg
Machine Weight	3300Kg	4000Kg	5100Kg
Overall Dimensions (LWH)	4850X2730X1700mm	6015X2730X1700mm	6015X3300X1700mm

Application Example

Fiber laser cutting machine is used in sheet metal processing, advertising sign production, cabinet electrical cabinets,mechanical
 parts, kitchenware, sanitary ware, auto parts, machinery manufacturing,metal crafts, saw blades, electrical parts,glasses
 industry, spring sheets, circuit boards,electrical Kettles, medical microelectronics, hardware, doors and windows and other
 industries.

Packaging＆Shipping
1. Outside package: Standard marine export plywood case.2. Inner package: Stretchy film and plastic film for humidity. We can
 package according to your requests. Delivery Detail: Shipped in 15-30 working days after payment.


Certifications

Exhibition

Product Tags:

sheet fiber laser cutting machine

cnc laser cutting machine

fiber laser metal cutting machine

6015 MAX 12000W Fiber Laser Metal Engraving Machine Cnc Laser Cutting Machine Images
